SGA-2163Z RF Micro Devices SGA-2163Z Real Image
Same model may have multiple batches, images only for reference.
SGA-2163Z RF Micro Devices SGA-2163Z Real Image
SGA-2163Z RF Micro Devices SGA-2163Z Real Image
Same model may have multiple batches, images only for reference.

SGA-2163Z

Part No SGA-2163Z
Manufacturer RF Micro Devices
Catalog RF Amplifiers
Description RF Amp Single Cascadable Amp 5GHz 2.5V 6-Pin SOT-363 T/R / IC AMP HBT SIGE 5000MHZ SOT-363
Datasheet
SGA-2163Z Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories RF/IF and RFID
Manufacturer RF Micro Devices
Packaging Reel - TR
Status Obsolete(EOL)
Frequency 0Hz to 5GHz
P1dB 6.2dBm (4.2mW)
Gain 9.8dB
Noise Figure 4.4dB
RF Type Cellular, GSM, PCS, UMTS
Supply Voltage - Operating 1.9 V to 2.5 V
Operating Supply Current 17mA to 23mA
Test Frequency 1.95GHz
Case / Package SOT-363
Win Source Part Number 028294-SGA-2163Z
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Family Name SGA-2163
Introduction Date November 19, 2009
ECCN 5A991.g
Estimated EOL Date Obsolete / End of life
Ultra Librarian 3D Model Ultra Librarian SGA-2163Z CAD Model

Description

The RF Micro Devices 028294-SGA-2163Z is an electronic component that is used in various applications such as cellular, GSM, PCS, and UMTS.

  • Case/Package: SOT-363
  • Supply Voltage Range: 1.9 V to 2.5 V
  • Status: obsolete (EOL)
