SBB-5089Z RF Micro Devices SBB-5089Z real image
Same model may have multiple batches, images only for reference.
SBB-5089Z RF Micro Devices SBB-5089Z real image
SBB-5089Z RF Micro Devices SBB-5089Z real image
Same model may have multiple batches, images only for reference.

SBB-5089Z

Part No SBB-5089Z
Manufacturer RF Micro Devices
Catalog RF Amplifiers
Description IC AMP HBT 6000MHZ SOT-89
Datasheet
SBB-5089Z Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories RF/IF and RFID
Manufacturer RF Micro Devices
Packaging Reel - TR
Status Active
Frequency 50MHz to 6GHz
P1dB 19dBm (79.4mW) to 20.5dBm (112.2mW)
Gain 14.5dB to 17.5dB
Noise Figure 4.2dB to 4.9dB
RF Type Cellular, GSM, PCS, UMTS
Supply Voltage - Operating 5 V to 5.25 V
Operating Supply Current 65mA to 92mA
Test Frequency 1.95GHz
Case / Package SOT-89-3
Win Source Part Number 028042-SBB-5089Z
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian SBB-5089Z CAD Model

Description

The RF Micro Devices 028042-SBB-5089Z is a high popularity electronic component which is currently in balance in terms of supply and demand.

  • Manufacturer: RF Micro Devices
  • Frequency Range: 50MHz to 6GHz
  • Gain: 14.5dB to 17.5dB
  • Noise Figure: 4.2dB to 4.9dB
  • P1dB: 19dBm (79.4mW) to 20.5dBm (112.2mW)
  • Type: Active component
  • Case: SOT-89-3
  • Operating Supply Voltage: 5V to 5.25V
  • Operating Supply Current: 65mA to 92mA
