UPD78F0562MC-CAA-AX Real Image UPD78F0562MC-CAA-AX real image15076
Same model may have multiple batches, images only for reference.
UPD78F0562MC-CAA-AX Real Image UPD78F0562MC-CAA-AX real image15076
UPD78F0562MC-CAA-AX Real Image UPD78F0562MC-CAA-AX real image15076
Same model may have multiple batches, images only for reference.

UPD78F0562MC-CAA-AX

Part No UPD78F0562MC-CAA-AX
Manufacturer Renesas Electronics America
Catalog Embedded - Microcontrollers
Description IC MCU 8BIT 16KB FLASH 20SSOP / MCU 8-bit 78K0 CISC 16KB Flash 3.3V/5V 20-Pin SSOP
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits (ICs)
Manufacturer Renesas Electronics America
Series 78K0/Kx2-L
Packaging Tray
Core Processor 78K/0
Core Size 8-Bit
Speed 10MHz
Connectivity I2C, LIN, UART/USART
Peripherals LVD, POR, PWM, WDT
Number of I/O 13
Program Memory Size 16KB (16K x 8)
Program Memory Type FLASH
RAM Size 768 x 8
Supply Voltage 1.8 V ~ 5.5 V
Data Converters A/D 6x10b
Oscillator Type Internal
Operating Temperature Range -40°C ~ 85°C (TA)
Package 20-LSSOP (0.240", 6.10mm Width)
Win Source Part Number 798872-UPD78F0562MC-CAA-AX
Popularity Medium
Supply and Demand Status Limited
Quantity per package 240
Family Name UPD78F0562MC
Introduction Date September 03, 2009
ECCN EAR99
Country of Origin Japan
Estimated EOL Date 2022
Ultra Librarian 3D Model Ultra Librarian UPD78F0562MC-CAA-AX CAD Model

Description

The UPD78F0562MC-CAA-AX is an integrated circuit from Renesas Electronics America.

  • Series: 78K0/Kx2-L
  • Package: Tray
  • Operating Temperature Range: -40°C to 85°C
  • Core Processor: 78K/0
  • Speed: 10MHz
  • Package: 20-LSSOP
  • Core Size: 8-bit
  • Connectivity: I2C, LIN, UART/USART
  • Peripherals: LVD, POR, PWM, WDT
  • I/Os: 13
  • Program Memory Size: 16KB (16K x 8)
  • Program Memory Type: FLASH
  • RAM Size: 768 x 8
  • A/D: 6x10b
  • Oscillator Type: Internal
  • Supply Voltage: 1.8V to 5.5V
  • Units per Package: 240
  • Estimated EOL Date: 2022
