Same model may have multiple batches, images only for reference.
R570313000 Real Image
Same model may have multiple batches, images only for reference.

R570313000

Part No R570313000
Manufacturer Radiall USA, Inc.
Catalog RF Switches
Description IC RF SWITCH SPDT 3GHZ MODULE / RF Switch IC General Purpose SPDT 50Ohm Module
Datasheet
R570313000 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category RF and Wireless - RF Switches
Mfr Radiall USA, Inc.
Package Bulk
Product Status Active
RF Type General Purpose
Circuit SPDT
Frequency Range 0Hz ~ 3GHz
Isolation 80dB (min)
Insertion Loss 0.15dB (max)
Test Frequency 3GHz
Impedance 50Ohm
Voltage - Supply 24V ~ 30V
Temperature Range - Operating -40°C ~ 85°C
Package / Case Module, SMA Connectors
Supplier Device Package Module
Standard Package 1 pcs
MSL Level 1 (Unlimited)
ECCN EAR99
HTSUS 8543.70.9860
Win Source Part Number 890957-R570313000
Ultra Librarian 3D Model Ultra Librarian R570313000 CAD Model

Description

The 890957-R570313000 is an RF switch designed for general-purpose applications.

  • Frequency Range: 0Hz to 3GHz
  • Insertion Loss: 0.15dB (max)
  • Isolation: 80dB (min)
  • Circuit Configuration: SPDT
  • Voltage Supply: 24V to 30V
  • Package: Module with SMA connectors
  • Manufacturer: Radiall USA, Inc.
  • Product Category: RF and Wireless
  • Product Status: Active
