The PE-5160X is a high-performance Ethernet pulse transformer manufactured by Pulse Electronics. This component is specifically designed to meet the demanding requirements of Ethernet applications, providing signal isolation and impedance matching for reliable data transmission over network cables. It is engineered for use in various networking devices and systems.

Applications

• Ethernet network interface cards (NICs)
• Routers
• Switches
• Hubs
• Embedded networking systems

Features

• Designed for Ethernet applications
• Provides electrical isolation between the PHY and the Ethernet cable
• Improves signal integrity by matching impedance
• Compact size for space-constrained applications
• High performance and reliability
• Compliant with IEEE 802.3 standards

Benefits

• Enhanced data transmission reliability
• Protection against voltage surges and electrical noise
• Improved signal quality for faster data rates
• Reduced electromagnetic interference (EMI)
• Increased system stability
• Ensures compliance with industry standards

Additional Details
