PA1138NLT Real Image PA1138NLT real image PA1138NLT real image12808 PA1138NLT real image12809
Same model may have multiple batches, images only for reference.
PA1138NLT Real Image PA1138NLT real image PA1138NLT real image12808 PA1138NLT real image12809
PA1138NLT Real Image PA1138NLT real image PA1138NLT real image12808 PA1138NLT real image12809
Same model may have multiple batches, images only for reference.

PA1138NLT

Part No PA1138NLT
Manufacturer Pulse
Catalog Pulse Transformers
Description XFRMR 12V 13.5W 127UH POE EP13 / 127μH Isolation and Data Interface (Encapsulated) Pulse Transformer 1:0.292:0.208 Surface Mount
Datasheet
PA1138NLT Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Transformers - Pulse Transformers
Mfr Pulse
Series EP13
Package Tape & Reel
Product Status Active
Transformer Type Isolation and Data Interface (Encapsulated)
Inductance 127µH
Mounting Type Surface Mount
Size / Dimension 0.551" L x 0.695" W (14.00mm x 17.65mm)
Height - Seated (Max) 0.500" (12.70mm)
Temperature Range - Operating -40°C ~ 125°C
Standard Package 150 pcs
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8504.31.2000
Win Source Part Number 652335-PA1138NLT
Ultra Librarian 3D Model Ultra Librarian PA1138NLT CAD Model

Description

The 652335-PA1138NLT is a pulse transformer designed for use in transformers - pulse transformer applications.

  • Application: Isolation and data interface (encapsulated)
  • Inductance: 127 µH
  • Package: Tape & Reel
  • Dimensions: 0.551" L x 0.695" W (14.00mm x 17.65mm)
  • Maximum Seated Height: 0.500" (12.70mm)
  • Mounting Type: Surface Mount
  • Operating Temperature: -40°C to 125°C
  • Manufacturer: Pulse
  • Standard Package: 150 pieces
  • ECCN: EAR99
  • MSL Level: 1 (Unlimited)
  • REACH: Unaffected
  • HTSUS Code: 8504.31.2000
