P0397NLT Real Image
Same model may have multiple batches, images only for reference.

P0397NLT

Part No P0397NLT
Manufacturer Pulse
Catalog Arrays, Signal Transformers
Description INDUCT ARRAY 2 COIL 5.9UH SMD
Datasheet
P0397NLT Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Inductors, Coils, Chokes
Manufacturer Pulse Electronics Corporation
Packaging Reel - TR
Status Active
Number of Coils 2
Test Inductance - Connected In Series 23.7μH
Inductance - Connected In Parallel 5.9μH
Tolerance ±20%
Current Rating - Parallel 8.2A
Current Rating - Series 4.1A
DC Resistance (DCR) - Parallel 10.47 mOhm
DC Resistance (DCR) - Series 41.9 mOhm
Temperature Range - Operating -40°C to 130°C
Mounting SMD (SMT)
Height 0.310" (7.87mm)
Win Source Part Number 209534-P0397NLT
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian P0397NLT CAD Model

Description

The 209534-P0397NLT is a two-coil inductor with a height of 0.310 inches (7.87mm) from Pulse Electronics Corporation.

  • Height: 0.310 inches (7.87mm)
  • Mounting: SMD (SMT) technology
  • Tolerance: ±20%
  • Current Rating (Parallel): 8.2A
  • Current Rating (Series): 4.1A
  • DC Resistance (Parallel): 10.47 mOhm
  • DC Resistance (Series): 41.9 mOhm
  • Packaging: Reel-TR
