H5120NL Real Image
Same model may have multiple batches, images only for reference.

H5120NL

Part No H5120NL
Manufacturer Pulse
Catalog Pulse Transformers
Description 1000base -t magnetics module Designed to Support Gigabit Transceivers | MODULE XFORMR SNGL GIGABIT SMD
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Transformers
Manufacturer Pulse Electronics Network
Packaging Tube
Mounting Style SMD
Parts Dimension 0.650" L x 0.365" W (16.51mm x 9.27mm)
Height - Seated (Maximum) 0.082" (2.08mm)
Temperature Range - Operating 0°C ~ 70°C
Manufacturer Pack Quantity 30
MSL Level 1 (Unlimited)
Win Source Part Number 1178298-H5120NL
Manufacturer Homepage www.pulseeng.com
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian H5120NL CAD Model

Description

The Pulse Electronics Network transformer is a high-quality transformer designed for use in electronic devices that require reliable and efficient power transmission.

  • Height: 0.082 inches
  • Operating Temperature Range: 0°C to 70°C
