BV030-7162.0 Real Image
Same model may have multiple batches, images only for reference.

BV030-7162.0

Part No BV030-7162.0
Manufacturer Pulse
Catalog Power Transformers
Description PWR XFMR LAMINATED 1.5VA TH  /
Datasheet
BV030-7162.0 Datasheet
Sample
Rohs State Need to verify
ECAD Module
Need Help

Products specifications Report Issue?

Category Transformers>Power Transformers
Mfr Pulse Electronics Power
Product Status Obsolete
Type Laminated Core
Voltage - Primary 230V
Voltage - Secondary (Full Load) 12V
Current - Output (Max) 125mA
Primary Winding(s) Single
Secondary Winding(s) Single
Center Tap No
Power - Max 1.5VA
Mounting Type Through Hole
Termination Style PC Pin
Dimension 32.50mm L x 27.50mm W
Height - Seated (Max) 24.00mm
Weight 0.133 lb (60.33 g)
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8504.31.4035
Other Names 030-7162-0,030-7162.0,567-1032-5,567-1032-5-NDR,BV 030-7162.0,BV0307162.0
Standard Package 150
Win Source Part Number 1199039-BV030-7162.0
Ultra Librarian 3D Model Ultra Librarian BV030-7162.0 CAD Model

Description

The Pulse BV030-7162.0 is a laminated core type power transformer with PC pin termination style.

  • Maximum Power: 1.5VA
  • Weight: 0.133 lb (60.33 g)
  • Voltage Isolation: Unspecified
  • Supplier Device Package: Unspecified
  • Voltage Primary: 230V
  • Current Output (Max): 125mA
  • Voltage Secondary (Full Load): 12V
  • Height: 24.00mm
  • Dimension: 32.50mm L x 27.50mm W
  • Status: Obsolete
