PE42426A-Z
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Categories RF/IF and RFID
Estimated Pruduction Lead Time 27 Weeks
Features RF Switch IC - SPDT 50Ohm 12-QFN (3x3)
Manufacturer pSemi
Package Reel - TR
Operating Temperature Range -40°C ~ 105°C
Package 12-WFQFN Exposed Pad
Case / Package 12-QFN (3x3)
Family Name PE42426
MSL Level Not Applicable
ECCN EAR99
HTSUS 8542.39.0001
Other Part Number 1046-1161-6, 1046-1161-1, 1046-1161-2
Quantity per package 3000
Popularity High
Supply and Demand Status Balance
Win Source Part Number 930198-PE42426A-Z
Ultra Librarian 3D Model Ultra Librarian PE42426A-Z CAD Model

Description

The PE42426A-Z from pSemi is an RF switch IC that is designed to offer SPDT 50Ohm performance.

  • Ideal for: Applications that require a compact and high-performance switch
  • Operating Temperature Range: Between -40°C and 105°C
  • Package: 12-WFQFN exposed pad
  • Packaging: Reel
  • Category: RF/IF and RFID
  • Family: PE42426
  • Popularity: High
  • Supply and Demand Balance: Yes
  • Estimated Production Lead Time: 27 weeks
  • HTSUS Code: 8542.39.0001
