TOP224PN Real Image TOP224PN Real Image
Same model may have multiple batches, images only for reference.
TOP224PN Real Image TOP224PN Real Image
TOP224PN Real Image TOP224PN Real Image
Same model may have multiple batches, images only for reference.

TOP224PN

Part No TOP224PN
Manufacturer Power Integrations
Catalog PMIC - AC DC Converters, Offline Switchers
Description IC OFFLINE SWIT PWM OCP HV 8DIP
Datasheet
TOP224PN Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Power Integrations
Packaging Tube/Rail
Status Not For New Designs
Output Isolation Isolated
Internal Switch(s) Yes
Voltage - Breakdown 700V
Topology Boost, Buck, Flyback, Forward
Duty Cycle 67%
Frequency - Switching 100kHz
Power (Watts) 30W
Fault Protection Current Limiting, Over Temperature
Control Operating Temperature -40°C to 150°C (TJ)
Case / Package 8-DIP
Mounting Through Hole
Win Source Part Number 033354-TOP224PN
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian TOP224PN CAD Model

Description

The Power Integrations TOP224PN is an isolated integrated circuit with a power of 30W and voltage breakdown of 700V.

  • Topology: Boost, buck, flyback, forward topology
  • Duty Cycle: 67%
  • Frequency Switching: 100kHz
  • Internal Switches: Internal switches
  • Fault Protection: current limiting and over-temperature protection
  • Mounting Type: through-hole
  • Temperature Range: -40°C to 150°C (TJ)
  • Product Status: not for new designs
  • Case/Package: 8-DIP
  • Win Source Part Number: 033354-TOP224PN
