3283

Part No 3283
Manufacturer Pomona Electronics
Catalog Coaxial Connectors (RF)
Description CONN ADAPT JACK-JACK BNC 50 OHM
Datasheet
3283 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Connectors, Interconnects - Coaxial Connectors (RF) - Coaxial Connector (RF) Adapters
Mfr Pomona Electronics
Package Bulk
Product Status Active
Adapter Type Jack to Jack
Conversion Type Same Series
Adapter Series BNC to BNC
Center Gender Female to Female
Convert From (Adapter End) BNC Jack, Female Socket
Convert To (Adapter End) BNC Jack, Female Socket
Impedance 50Ohm
Style Straight
Mounting Type Free Hanging (In-Line)
Fastening Type Bayonet Lock, Bayonet Lock
Center Contact Plating Gold
Body Material Brass
Center Contact Material Beryllium Copper
Dielectric Material Polytetrafluoroethylene (PTFE)
Temperature Range - Operating -65°C ~ 165°C
Standard Package 5 pcs
MSL Level Not Applicable
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8536.69.4010
Win Source Part Number 1125532-3283
Ultra Librarian 3D Model Ultra Librarian 3283 CAD Model

Description

The BNC Jack to Jack Coaxial Connector Adapter is a high-quality connector designed for use in coaxial cable applications.

  • Style: Straight
  • Fastening Type: Bayonet lock
  • Impedance: 50Ohm
  • Material: Brass
  • Center Contact Material: Beryllium copper with gold plating
  • Connection Type: Female to female
  • Series: BNC to BNC
  • Operating Temperatures: -65°C to 165°C
  • Package: Bulk package of 5 pcs.
