Same model may have multiple batches, images only for reference.
ECH-U1C822GX5 Real Image
Same model may have multiple batches, images only for reference.

ECH-U1C822GX5

Part No ECH-U1C822GX5
Manufacturer Panasonic
Catalog Film Capacitors
Description CAP FILM 8200PF 2% 16VDC 0805
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Capacitors
Manufacturer Panasonic Electronic Components
Packaging Reel - TR
Status Active
Capacitance 8200pF
Tolerance ±2%
Voltage Rating - DC 16V
Dielectric Material Polyphenylene Sulfide (PPS), Metallized - Stacked
Temperature Range - Operating -55°C to 125°C
Mounting SMD (SMT)
Dimension 0.079" L x 0.049" W (2.00mm x 1.25mm)
Height - Seated (Max) 0.051" (1.30mm)
Termination Solder Pads
Applications General Purpose
Win Source Part Number 000847-ECH-U1C822GX5
Popularity Medium
Supply and Demand Status Balance
Quantity per package 3k pcs
Ultra Librarian 3D Model Ultra Librarian ECH-U1C822GX5 CAD Model

Description

Description

The ECH-U1C822GX5 is a high-performance, multilayer ceramic capacitor designed for a wide range of electronic applications. Known for its reliability and durability, this capacitor excels in both commercial and industrial environments.

Features and Benefits

  • Compact size for easy integration into designs.
  • High capacitance stability across various temperatures.
  • Low equivalent series resistance (ESR) for improved efficiency.
  • RoHS compliant and environmentally friendly.

Applications

  • Power Supply Units (PSUs)
  • Telecommunication Equipment
  • Automotive Electronics
  • PCB Design Projects
