ECH-U1C222JX5 Real Image
Same model may have multiple batches, images only for reference.

ECH-U1C222JX5

Part No ECH-U1C222JX5
Manufacturer Panasonic
Catalog Film Capacitors
Description CAP FILM 2200PF 5% 16VDC 0603
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Capacitors
Manufacturer Panasonic Electronic Components
Packaging Reel - TR
Status Active
Capacitance 2200pF
Tolerance ±5%
Voltage Rating - DC 16V
Dielectric Material Polyphenylene Sulfide (PPS), Metallized - Stacked
Temperature Range - Operating -55°C to 125°C
Mounting SMD (SMT)
Dimension 0.063" L x 0.031" W (1.60mm x 0.80mm)
Height - Seated (Max) 0.033" (0.85mm)
Termination Solder Pads
Applications General Purpose
Win Source Part Number 101323-ECH-U1C222JX5
Popularity Medium
Supply and Demand Status Balance
Quantity per package 4k pcs
Ultra Librarian 3D Model Ultra Librarian ECH-U1C222JX5 CAD Model

Description

Product Description

Ideal for high-frequency and high-efficiency circuits, the ECH-U1C222JX5 multilayer ceramic capacitor provides unmatched performance stability and precision for today’s advanced electronics.

Applications

  • Aerospace Systems
  • High-Frequency Circuitry
  • Data Processing Devices
  • Control Systems
  • Electric Drives

Features and Benefits

  • Precision capacitance value with low variance
  • Compact dimensions for easy integration
  • High insulation resistance
  • Operational agility across diverse environmental conditions
  • Manufactured according to strict quality standards

This capacitor's innovative design contributes to reliable functioning in dynamic applications and boosts efficiency in energy conversion systems.
