DB3X313F0L Real Image DB3X313F0L Real Image
Same model may have multiple batches, images only for reference.
DB3X313F0L Real Image DB3X313F0L Real Image
DB3X313F0L Real Image DB3X313F0L Real Image
Same model may have multiple batches, images only for reference.

DB3X313F0L

Part No DB3X313F0L
Manufacturer Panasonic
Catalog Diodes, Rectifiers - Arrays
Description DIODE ARRAY SCHOTTKY 30V MINI3
Datasheet
DB3X313F0L Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Panasonic Electronic Components
Packaging Reel - TR
Status Active
Diode Configuration 1 Pair Series Connection
Diode Type Schottky
Voltage - DC Reverse (Vr) (Max) 30V
Current - Average Rectified (Io) (per Diode) 200mA
Voltage - Forward (Vf) (Max) @ If 550mV @ 200mA
Reverse Recovery Time (trr) 1.5ns
Current - Reverse Leakage @ Vr 50μA @ 30V
Operating Temperature - Junction 125°C (Max)
Mounting SMD (SMT)
Case / Package Mini3-G3-B
Win Source Part Number 1032681-DB3X313F0L
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian DB3X313F0L CAD Model

Description

The DB3X313F0L is a Schottky diode manufactured by Panasonic Electronic Components.

  • Supply and Demand: Balanced
  • Voltage - DC Reverse (Vr) (Max): 30V
  • Voltage - Forward (Vf) (Max) @ If: 550mV @ 200mA
