AXK6F16337YG

Part No AXK6F16337YG
Manufacturer Panasonic
Catalog Rectangular - Board to Board Connectors
Description CONN HEADER BRD/BRD .5MM 16POS
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Connectors, Interconnects
Manufacturer Panasonic Electric Works
Packaging Reel - TR
Status Active
Connector Type Header, Center Strip Contacts
Number of Positions 16
Pitch 0.020" (0.50mm)
Number of Rows 2
Mounting SMD (SMT)
Features Board Guide
Contact Finish Gold
Mated Stacking Heights 1.5mm, 2mm
Height Above Board 0.049" (1.25mm)
Win Source Part Number 199542-AXK6F16337YG
Popularity Medium
Supply and Demand Status Balance
Quantity per package 2k pcs
Ultra Librarian 3D Model Ultra Librarian AXK6F16337YG CAD Model

Description

AXK6F16337YG Connector

The AXK6F16337YG provides a reliable solution for interconnect applications demanding compact design and high performance. This board-to-board connector supports efficient power and signal transmission, contributing to seamless integration in sophisticated electronic devices.

  • Reliable solution for compact interconnects
  • Efficient power and signal transmission
  • Seamless integration into electronic devices

Applications:

  • Wearable technology
  • Consumer electronics
  • Automotive systems
  • Medical equipment

Features & Benefits:

  • Sturdy build ensures durability under tough conditions
  • Streamlined design conserves space
  • Easy assembly reduces installation costs and time
  • High endurance to thermal cycling
