APAN3124 Real Image APAN3124 real image24022
Same model may have multiple batches, images only for reference.
APAN3124 Real Image APAN3124 real image24022
APAN3124 Real Image APAN3124 real image24022
Same model may have multiple batches, images only for reference.

APAN3124

Part No APAN3124
Manufacturer Panasonic
Catalog Power Relays, Over 2 Amps
Description RELAY GEN PURPOSE SPST 5A 24V / General Purpose Relay SPST-NO (1 Form A) 24VDC Coil Through Hole
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Relays - Power Relays, Over 2 Amps
Mfr Panasonic
Series PA-N
Package Tube
Product Status Active
Mounting Type Through Hole
Coil Voltage 24VDC
Contact Form SPST-NO (1 Form A)
Contact Rating (Current) 5 A
Switching Voltage 250VAC, 110VDC - Max
Coil Current 4.6 mA
Coil Type Non Latching
Termination Style PC Pin
Seal Rating Sealed - Fully
Must Operate Voltage 16.8 VDC
Must Release Voltage 1.2 VDC
Operate Time 10 ms
Release Time 5 ms
Temperature Range - Operating -40°C ~ 90°C
Contact Material Silver Nickel (AgNi), Gold (Au)
Relay Type General Purpose
Coil Resistance 5.24 kOhms
Base Product Number APAN31
Standard Package 25 pcs
MSL Level 1 (Unlimited)
ECCN EAR99
HTSUS 8536.41.0020
Win Source Part Number 849115-APAN3124
Ultra Librarian 3D Model Ultra Librarian APAN3124 CAD Model

Description

The APAN3124 is a power relay with a single-pole, single-throw normally open contact configuration.

  • Coil Resistance: 5.24 kOhms
  • Coil Current: 4.6 mA
  • Coil Voltage: 24VDC
  • Contact Rating: 5A
  • Application: General-Purpose
  • Protection: Sealed
  • Manufacturer: Panasonic
  • Package: Tube
  • Standard Package: 25 pcs
  • Temperature Range: -40°C to 90°C
  • ECCN: Compliant
