ALF1P24 Real Image
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Categories Relays
Manufacturer Panasonic Electric Works
Packaging Box
Mounting Style Through Hole
Coil Voltage 24VDC
Contact Form SPST-NO (1 Form A)
Contact Rating (Current) 20A
Switching Voltage 250VAC - Max
Coil Current 37.5mA
Coil Type Non Latching
Termination Style PC Pin
Must Operate Voltage 16.8 VDC
Must Release Voltage 2.4 VDC
Operate Time 20ms
Release Time 15ms
Temperature Range - Operating -40°C ~ 60°C
Contact Material Silver Tin Oxide (AgSnO)
Relay Type General Purpose
Coil Resistance 640 Ohms
Manufacturer Pack Quantity 50
MSL Level 1 (Unlimited)
Win Source Part Number 1143329-ALF1P24
Manufacturer Homepage 0
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian ALF1P24 CAD Model

Description

The Panasonic Electric Works ALF1P24 is a general-purpose relay with SPST-NO (1 Form A) configuration and 24VDC coil.

  • Contact rating: 20A
  • Switching voltage: 250VAC - Max
  • Mounting: through-hole
  • Operating temperature range: -40°C to 60°C
  • Contact material: silver tin oxide (AgSnO)
  • Packaging: box
  • Manufacturer pack quantity: 50
  • Popularity: medium
  • Supply and demand status: limited
