Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer ON Semiconductor
Packaging Reel - TR
Status Active
Diode Type Schottky
Voltage - DC Reverse (Vr) (Max) 60V
Current - Average Rectified (Io) 2A
Voltage - Forward (Vf) (Max) @ If 630mV @ 2A
Speed(Frequency) Fast Recovery = 200mA (Io)
Current - Reverse Leakage @ Vr 200μA @ 60V
Mounting SMD (SMT)
Case / Package SMB
Operating Temperature - Junction -55°C to 150°C
Win Source Part Number 030832-SS26T3G
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Application Field Used in Power Management, Automotive, Industrial
Family Name SS26
Introduction Date September 04, 2001
ECCN EAR99
Country of Origin Malaysia
Halogen Free Compliant
Estimated EOL Date 2026
Ultra Librarian 3D Model Ultra Librarian SS26T3G CAD Model

Description

ON Semiconductor SS26T3G Schottky Barrier Rectifier

The SS26T3G from ON Semiconductor is a highly efficient, surface-mount Schottky Barrier Rectifier designed for applications requiring low voltage, high-frequency rectification, and freewheeling in power management systems. This Schottky diode is a popular choice among engineers due to its compact SMA package, which makes it suitable for high-density circuit board designs.

With its Schottky Barrier technology, the SS26T3G offers a superior forward voltage drop compared to traditional PN junction rectifiers. This results in reduced power loss and improved efficiency, making it ideal for use in power supply circuits, DC-DC converters, and reverse battery protection circuits. Its low forward voltage drop also means less heat generation, which enhances the reliability and longevity of the device under typical operating conditions.

The SS26T3G boasts a peak repetitive reverse voltage (VRRM) of 60 volts and a forward continuous current (IF) of 2 amperes, which allows it to handle moderate power requirements with ease. Additionally, its fast switching capability ensures that the device can cope with high-frequency operations without significant losses, thus providing a performance advantage in switching applications.

This rectifier is also characterized by its low leakage current, which minimizes power drain when the device is in the off state. Its operating junction temperature range of -55°C to +150°C ensures that the SS26T3G can perform reliably in a wide range of environmental conditions, making it suitable for various industrial and commercial applications.

The SS26T3G is provided in a RoHS-compliant and halogen-free package, reflecting ON Semiconductor's commitment to environmental sustainability. Its lead-free finish and compliance with current environmental standards make it an eco-friendly choice for manufacturers looking to create green products.

In summary, the ON Semiconductor SS26T3G Schottky Barrier Rectifier is a robust, high-performance component designed to meet the needs of modern electronic circuits. Its combination of efficiency, thermal performance, and environmental compliance makes it an excellent choice for designers seeking a reliable and responsible solution for their rectification needs.
