NB3L8533DTG ON Semiconductor – Price, Stock & Datasheet
Same model may have multiple batches, images only for reference.

NB3L8533DTG

Part No NB3L8533DTG
Manufacturer ON Semiconductor
Catalog Clock/Timing - Clock Buffers, Drivers
Description IC CLK BUFFER 2:4 650MHZ 20TSSOP
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Product Status Obsolete
Type Fanout Buffer (Distribution), Multiplexer
Number of Circuits 1
Ratio - Input 2:4
Differential - Input Yes/Yes
Input CML, HCSL, HSTL, LVDS, LVPECL, SSTL
Output LVPECL
Frequency - Max 650 MHz
Voltage - Supply 2.375V ~ 3.63V
Temperature Range - Operating -40°C ~ 85°C
Mounting Type Surface Mount
Case / Package 20-TSSOP (0.173", 4.40mm Width)
Supplier Device Package 20-TSSOP
Package Tube
Supply and Demand Status Shortage
Win Source Part Number 1499834-NB3L8533DTG
Ultra Librarian 3D Model Ultra Librarian NB3L8533DTG CAD Model

Description

N
