The MCR100-8RL from ON Semiconductor is a highly efficient silicon controlled rectifier (SCR) that is designed to cater to a wide range of applications requiring controlled rectification and phase control. This SCR is a member of the MCR100 series and is well-suited for applications in the automotive, industrial, and consumer markets.

Key Features

• Voltage Capacity: The MCR100-8RL has a peak repetitive off-state voltage (V_DRM) of 600V, making it suitable for medium voltage applications.
• Current Rating: It can handle a continuous on-state current (I_T) of up to 0.8A, which is ideal for moderate current control applications.
• Gate Trigger Current: The device has a low gate trigger current (I_GT) of 200µA, ensuring that it can be triggered with minimal control current, making it energy-efficient.
• Surge Capability: The MCR100-8RL is capable of withstanding surge currents, offering a non-repetitive on-state current (I_TSM) of 10A, which is crucial for applications that may experience short-term overloads.
• Thermal Characteristics: With an operating junction temperature range of -40°C to +110°C, it is designed to perform reliably in a broad range of environmental conditions.
• Package: The device comes in a TO-92 package, which is compact and suitable for through-hole mounting, providing ease of integration into various circuit designs.

Applications

The versatility of the MCR100-8RL allows it to be used in a variety of applications, including:

• Ignition circuits
• Motor control circuits
• Overvoltage crowbar protection
• Capacitive discharge ignitions
• Voltage regulation circuits
• Controlled rectifier applications

Reliability and Quality

ON Semiconductor is known for its commitment to quality and reliability, and the MCR100-8RL is no exception. Each SCR is manufactured to meet stringent standards, ensuring that it performs to the highest specifications and delivers consistent results across its lifespan.

Product Code: MCR100-8RL
