ON Semiconductor MC74VHC1G04DFT2G Inverter

The ON Semiconductor MC74VHC1G04DFT2G is a high-speed CMOS inverter integrated circuit (IC) designed to address a wide range of applications in modern electronics. This single-gate logic inverter is part of the VHC family, known for its high noise immunity and low power consumption. It is particularly well-suited for interfacing with high-speed logic systems and is compatible with TTL (Transistor-Transistor Logic) levels.

Encased in a compact SOT-353 (SC-70) surface-mount package, the MC74VHC1G04DFT2G is optimized for minimal space usage on printed circuit boards (PCBs), making it an excellent choice for space-constrained applications. The device operates over a broad voltage range of 2V to 5.5V, providing a flexible solution for systems that require operation at various logic levels.

One of the key features of the MC74VHC1G04DFT2G is its high-speed performance. With a typical propagation delay time of only 3.9ns at 5V, it is capable of fast signal processing, which is essential for high-speed computing and data communication applications. Additionally, the low power dissipation of the device, with a quiescent current of 2µA, makes it an energy-efficient choice for battery-operated devices.

The inverter's input is designed to tolerate voltages up to 7V, allowing for a certain degree of voltage overshoot and undershoot during transitions, which contributes to its robustness in harsh electrical environments. The MC74VHC1G04DFT2G also features balanced output drive with current sinking and sourcing capabilities, which ensures symmetrical high-impedance outputs and enhances its compatibility with a wide range of subsequent circuit stages.

In summary, the ON Semiconductor MC74VHC1G04DFT2G is a versatile and reliable inverter chip that combines high-speed operation, low power consumption, and compact packaging. It is an ideal choice for designers looking for a logic-level conversion solution that can operate efficiently in both power-sensitive and space-limited applications.
