Product Overview: MC74LV594ADTR2G

The MC74LV594ADTR2G from ON Semiconductor is a high-performance 8-bit shift register that operates at a low-voltage and high-speed. It is part of the 74LV family of devices, which are known for their low-voltage operation and low power consumption. This particular device is designed for use in applications requiring the capture and control of data, such as in digital systems, where it can be used to serialize data for transmission or to provide additional parallel outputs.

Key Features

• Low Voltage Operation: The device operates at a voltage range of 2.0V to 5.5V, making it suitable for battery-operated and low-power applications.
• High-Speed Performance: With a high clock rate, the MC74LV594ADTR2G is capable of handling fast data rates, making it ideal for high-speed data logging and processing tasks.
• Serial-to-Parallel Data Conversion: The shift register allows for serial input to be converted into parallel output, thus enabling easy interfacing with microcontrollers and other digital systems.
• Output Drive Capability: The device can drive up to 5.2mA at the output, providing robust signal transmission to connected components.
• Edge-Triggered Clock: The shift register utilizes a positive-edge triggered clock, ensuring precise timing for data capture and shifting operations.

Applications

The MC74LV594ADTR2G is versatile and can be used in a wide range of applications, including:

• Portable and battery-powered devices
• Microcontroller interfacing
• Data acquisition systems
• Communication systems
• Digital signal processing

Package and Quality

This device comes in a TSSOP-16 package, which is known for its small footprint and suitability for space-constrained applications. The MC74LV594ADTR2G is also available in tape and reel packaging, which facilitates automated assembly processes. ON Semiconductor ensures high-quality standards, and this product is no exception, adhering to stringent industry quality norms and reliability testing protocols.
