ON Semiconductor MC33074ADTBR2G Operational Amplifier

The MC33074ADTBR2G is a high-performance operational amplifier (op-amp) designed by ON Semiconductor, renowned for its precision and stability. This op-amp is part of a product family that features a range of amplifiers with different configurations to suit various applications. The MC33074ADTBR2G is particularly well-suited for applications requiring low input offset voltage, low input bias current, and high gain bandwidth product.

Constructed with Bipolar technology, the MC33074ADTBR2G offers a unique combination of high speed, wide bandwidth, and low noise. With a typical gain bandwidth product of 4.5 MHz, it is capable of accommodating a wide range of frequencies, which makes it ideal for audio processing, active filters, and fast signal conditioning circuits. The operational amplifier operates on a single or dual supply voltage, ranging from 3V to 44V, providing flexibility in various power environments.

The MC33074ADTBR2G op-amp is packaged in a TSSOP-14 (Thin Shrink Small Outline Package) which is compact and suitable for space-constrained applications. It also offers improved thermal performance, which is crucial for maintaining stability and longevity in high-performance systems.

Key features of the MC33074ADTBR2G include:

• Single or dual supply operation: 3V to 44V
• Low input offset voltage: 2 mV
• Low input bias current: 500 nA
• High gain bandwidth product: 4.5 MHz
• Low total harmonic distortion
• Extended temperature range: -40°C to +125°C
• Short-circuit protection
• ESD clamps on the inputs to prevent damage from electrostatic discharge

Applications that can benefit from the MC33074ADTBR2G include:

• Precision analog circuits
• Data acquisition systems
• Instrumentation
• Audio processing equipment
• Active filters and comparators

ON Semiconductor's commitment to high-quality and reliable components is evident in the MC33074ADTBR2G op-amp. It is an excellent choice for engineers and designers looking for an operational amplifier that provides precision, low noise, and high-speed performance in a variety of electronic applications.
