Categories Integrated Circuits
Manufacturer ON Semiconductor
Packaging Tube/Rail
Status Active
Motor Type - AC, DC Brushless DC (BLDC)
Purpose Controller - Commutation, Direction Management
Applications General Purpose
Supply Voltage - Operating 10 V to 30 V
Temperature Range - Operating -40°C to 85°C (TA)
Mounting SMD (SMT)
Case / Package 24-SOIC
Win Source Part Number 044433-MC33035DWG
Popularity Medium
Supply and Demand Status Limited
Application Field Used in Motor Drive & Control, Sensing & Instrumentation
Ultra Librarian 3D Model Ultra Librarian MC33035DWG CAD Model

Description

ON Semiconductor MC33035DWG Brushless DC Motor Controller

The MC33035DWG from ON Semiconductor is a high-performance brushless DC motor controller integrated circuit designed for the precise control of a variety of brushless DC motors. It is housed in a 24-pin wide body SOIC package, making it suitable for space-constrained applications while offering robust features for motor control applications.

This sophisticated device is capable of providing continuous phase current control through external drive circuitry, which is essential for applications requiring precise motor speed and torque control. The MC33035DWG integrates a variety of features including fixed frequency pulse width modulation (PWM), an internal ramp generator, a hall-effect sensor interface, and other circuitry necessary for the full control of a brushless motor.

Key features of the MC33035DWG include:

  • Supply voltage capability from 10V to 30V, which allows for use in a wide range of applications.
  • High-frequency operation up to 100kHz, which enables the use of smaller external components, reducing the overall solution size.
  • Undervoltage lockout (UVLO) and thermal shutdown features for enhanced safety and reliability.
  • Forward and reverse motor control which provides versatility in control for various application needs.
  • Integrated brake transistor for dynamic braking functionality, improving stopping and holding capabilities.

The MC33035DWG is suitable for a wide array of applications, including but not limited to automotive, industrial control systems, robotics, and HVAC systems. Its ability to drive complex motor designs with minimal external components makes it a go-to solution for engineers looking to develop efficient and reliable brushless DC motor systems.

ON Semiconductor's commitment to quality ensures that the MC33035DWG meets the stringent requirements for performance and durability, making it a reliable choice for your motor control needs. Whether you are designing a new system or upgrading an existing one, the MC33035DWG offers the functionality and performance to meet the challenges of modern brushless DC motor control.
