Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Motor Type - Stepper Unipolar
Motor Type - AC, DC Brushed DC
Purpose Driver - Fully Integrated, Control and Power Stage
Technology Power MOSFET
Applications General Purpose
Output Current 800mA
Supply Voltage - Operating 8.2 V to 60 V
Voltage - Load 8.2 V to 60 V
Temperature Range - Operating -40°C to 150°C (TJ)
Mounting SMD (SMT)
Case / Package 20-SOIC
Win Source Part Number 203345-DRV8803DWR
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian DRV8803DWR CAD Model

Description

DRV8803DWR Motor Driver

The DRV8803DWR is a robust motor driver designed to control a variety of motors in diverse applications, providing precision and stability. It is well-suited for industrial and consumer electronics projects that require efficient motor control.

  • Applications: Robotic arms, Conveyor belts, Automotive window lifts, Industrial automation systems
  • Features: Quadruple H-Bridge motor driver, Supports up to 2.8A per bridge, Wide operating voltage range of 8.2V to 45V, Built-in protection features including thermal shutdown, undervoltage lockout, and overcurrent protection
  • Benefits: High reliability in harsh environments, Compact SOP package, Easy integration into existing systems
  • The DRV8803DWR is an excellent choice for both low and high-power motor control applications, offering dependable performance and extensive protection mechanisms.
