ON Semiconductor MC14013BDT Dual Type D Flip-Flop

The MC14013BDT is a high-performance integrated circuit produced by ON Semiconductor, renowned for its reliability and versatility in various digital applications. This dual type D flip-flop is a fundamental building block in digital electronics, offering users a dependable solution for storage and transfer of digital information.

Constructed with MOS P-Channel and N-Channel enhancement mode devices in a single monolithic structure, the MC14013BDT exhibits robust characteristics that make it suitable for a wide range of applications, from simple data storage and transfer to more complex sequential logic operations. The flip-flop's dual design allows for compact circuitry while maintaining functionality, making it an excellent choice for space-conscious designs.

Key Features:

• Logic Type: Dual D-Type Flip-Flop
• Supply Voltage Range: 3V to 18V, accommodating a wide range of power requirements
• Output Current: High sink and source capability
• Clock Frequency: Capable of handling significant clock frequencies suitable for various digital applications
• Propagation Delay Time: Fast response time ensures quick switching and data transfer
• Operating Temperature: Designed to operate over a broad temperature range, ensuring reliability under varying environmental conditions
• Packaging: Available in a TSSOP-14 package, providing a compact footprint for space-efficient designs
• Lead-Free and RoHS Compliant: Meets current environmental standards, reducing hazardous substances in electronic devices

The MC14013BDT is equipped with set and reset functions, which can be used independently of the clock to initiate or halt the operation of the flip-flop. This feature adds an extra layer of control, making the device more flexible and adaptable to user requirements. Additionally, the symmetrical output impedance ensures balanced performance, and the high noise immunity provides stable operation even in electrically noisy environments.

Whether you're designing a new digital system or upgrading an existing one, the ON Semiconductor MC14013BDT dual type D flip-flop is a reliable and efficient choice that promises to deliver performance and durability. Its ease of integration and compliance with industry standards makes it a go-to component for engineers and designers looking for a high-quality flip-flop solution.
