MC100EP196FA

Part No MC100EP196FA
Manufacturer ON Semiconductor
Catalog Clock/Timing - Delay Lines
Description IC PROGRAM DELAY 3.3V ECL 32LQFP
Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Integrated Circuits (ICs) - Clock/Timing - Delay Lines
Mfr ON Semiconductor
Series 100EP
Package Tray
Product Status Obsolete
Base Product Number MC100EP196
Standard Package 250 pcs
MSL Level 2 (1 Year)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8542.39.0001
Win Source Part Number 634041-MC100EP196FA
Ultra Librarian 3D Model Ultra Librarian MC100EP196FA CAD Model

Description

ON Semiconductor MC100EP196FA: Precision LVPECL Programmable Delay Chip

The ON Semiconductor MC100EP196FA is a state-of-the-art programmable delay chip designed for high-speed signal processing applications. This device is part of the high-performance ECLinPS MAX™ family, which is renowned for delivering exceptional precision and reliability in signal timing management.

The MC100EP196FA operates with a 3.3 V or 5 V power supply and features a Low Voltage Positive Emitter Coupled Logic (LVPECL) interface, ensuring compatibility with a wide range of advanced digital systems. This programmable delay chip offers a fine delay adjustment granularity, which provides designers with the flexibility to precisely align signal timing to meet stringent system requirements.

With a fully differential design, the MC100EP196FA minimizes signal skew and crosstalk, ensuring the integrity of high-speed signals. The device is capable of handling clock frequencies up to 3 GHz, making it an ideal choice for applications such as clock distribution, signal synchronization, and pulse-width modulation in telecommunications, data communications, and test equipment.

The programmable nature of the MC100EP196FA allows for an adjustable delay range from 0 to 1,000 ps in 5 ps increments, providing precise control over signal timing. This feature is particularly beneficial in applications where phase alignment and timing calibration are critical.

The MC100EP196FA is housed in a compact 32-lead LQFP package, which saves valuable board space while providing excellent thermal performance. Its robust design ensures reliable operation over the industrial temperature range of -40°C to +85°C.

Key features of the ON Semiconductor MC100EP196FA include:

  • Programmable delay range with high resolution
  • LVPECL input and output levels
  • 3 GHz clock frequency handling capability
  • Differential design for signal integrity
  • Operates with 3.3 V or 5 V power supply
  • Industrial temperature range support
  • Compact 32-lead LQFP packaging

In summary, the ON Semiconductor MC100EP196FA is a versatile and precise programmable delay chip that delivers high-performance timing solutions for a variety of complex digital systems. Its advanced features and flexible design make it an invaluable component for engineers looking to optimize their high-speed signal processing applications.
