ON Semiconductor MBR0520LT1G Schottky Barrier Rectifier

The MBR0520LT1G from ON Semiconductor is a highly efficient, surface-mount Schottky Barrier Rectifier designed for use in low voltage, high-frequency inverters, free-wheeling, and polarity protection applications. This compact device is a popular choice among engineers and designers for its low forward voltage drop and high surge capability, making it suitable for a variety of electronic circuits.

Key Features

• Low Power Loss: The MBR0520LT1G features a low forward voltage drop, which results in a lower power loss during operation, enhancing overall efficiency.
• High Surge Capability: With its robust design, this rectifier can handle high surge currents, making it reliable for applications that may experience unexpected voltage spikes.
• Surface Mount Package: Its SOD-123 package is ideal for compact designs, allowing for efficient use of PCB space.
• Lead-Free and RoHS Compliant: The MBR0520LT1G is environmentally friendly, adhering to current RoHS directives, and is lead-free, which is essential for global commercial applications.
• Polarity Protection: This device is often used to protect other components from incorrect power supply connections.

Electrical Characteristics

• Peak Repetitive Reverse Voltage (Vrrm): 20V
• Average Rectified Forward Current (Io): 0.5A
• Max Forward Voltage (Vf): 0.385V at 0.5A
• Max Reverse Current (Ir): 30mA at 20V
• Operating Junction Temperature Range: -55°C to +125°C

The MBR0520LT1G Schottky Barrier Rectifier is an essential component for designers looking to maximize power efficiency and reliability in their electronic systems. Its small footprint, combined with its exceptional electrical characteristics, make it a versatile choice that can be used in a wide range of applications. Whether it's for consumer electronics, automotive modules, or industrial equipment, the MBR0520LT1G delivers performance that engineers can trust.

For detailed specifications and application notes, it is recommended to consult the official datasheet provided by ON Semiconductor.
