Products specifications Report Issue?

Reference Date Code 16+
Reference case DFN3
Manufacturer NXP
Manufacturer Homepage www.nxp.com
Win Source Part Number 715833-PTVS18VU1UPA
Popularity Low
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian PTVS18VU1UPA CAD Model

Description

The PTVS18VU1UPA from NXP Semiconductors is a state-of-the-art Transient Voltage Suppressor (TVS) designed to protect sensitive electronics from voltage spikes and surges. Ideal for safeguarding high-speed data lines and I/O interfaces, this robust unidirectional TVS diode is capable of dissipating high transient power and preventing damage due to electrostatic discharge (ESD), electrical fast transients (EFT), and other voltage-induced threats.

Key Features:

  • Stand-off Voltage: The device is designed to withstand voltages up to 18V, providing a high degree of protection for electronic circuits operating at this voltage level.
  • Peak Pulse Power: It boasts an impressive peak pulse power dissipation of 400W (10/1000µs waveform), ensuring that it can handle significant transient power spikes without failing.
  • Low Clamping Voltage: The PTVS18VU1UPA has a low clamping voltage, which means it responds quickly to voltage transients, clamping them effectively to protect downstream components.
  • High Surge Capability: It is capable of handling high surge currents, making it an ideal choice for applications that may be subjected to surges such as lightning strikes or switching surges.
  • Fast Response Time: With an extremely fast response time to transient events, this TVS diode ensures immediate protection for your circuitry.
  • Low Leakage Current: The device has a low leakage current in standby mode, which contributes to energy efficiency in the electronic systems where it is used.
  • Compact Package: Housed in a small SOD-128 plastic package, the PTVS18VU1UPA is ideal for space-constrained applications.

Applications:

Thanks to its robust protection capabilities, the PTVS18VU1UPA is well-suited for a wide range of applications, including:

  • Automotive electronics
  • Industrial control systems
  • Telecommunication devices
  • Power supply units
  • Portable electronics
  • Computer and peripheral devices

Whether you are designing a complex automotive system or a simple consumer electronic device, the PTVS18VU1UPA from NXP Semiconductors provides reliable and efficient protection against voltage transients, ensuring the longevity and stability of your electronic products.
