Products specifications Report Issue?

Manufacturer NXP
Win Source Part Number 1151449-BAS70-04W
Manufacturer Homepage www.nxp.com
Family Name BAS70-04W
Introduction Date August 01, 2003
ECCN EAR99
Country of Origin Malaysia
Halogen Free Compliant
Estimated EOL Date 2023
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Application Field Used in Industrial
Ultra Librarian 3D Model Ultra Librarian BAS70-04W CAD Model

Description

NXP BAS70-04W Schottky Diode

The NXP BAS70-04W is a high-performance Schottky diode designed to offer fast switching capabilities with low forward voltage drop. This diode is housed in a compact SOT-323 package, making it suitable for high-density circuit board applications where space is at a premium. The BAS70-04W is a surface-mounted device that is optimized for use in a variety of electronic circuits, including switching power supplies, converters, and high-frequency rectification circuits.

Key Features

  • Low Forward Voltage: The BAS70-04W provides a low forward voltage drop, which helps to reduce power loss and improve efficiency in electronic circuits.
  • Fast Switching Speed: This Schottky diode is capable of very fast switching operations, a critical feature for high-frequency applications.
  • Reverse Voltage: It can withstand a reverse voltage of up to 70 volts, making it suitable for various applications.
  • Low Capacitance: The device has low junction capacitance, which is advantageous for high-speed switching and high-frequency operations.
  • Surface Mount Package: The compact SOT-323 package allows for efficient use of PCB space and is ideal for automated assembly processes.

Typical Applications

The BAS70-04W is versatile and can be used in a range of applications. These include:

  • Switching power supplies
  • DC-DC converters
  • High-frequency rectification
  • Protection circuits
  • Reverse polarity protection
  • RF applications

Reliability and Quality

NXP is known for its commitment to quality, and the BAS70-04W is no exception. It is manufactured to meet high standards of reliability and performance. The device is characterized by its robust construction and long operational life, making it a reliable choice for both commercial and industrial electronic systems.

In summary, the NXP BAS70-04W Schottky diode is a high-quality component that delivers efficient, fast switching performance in a small footprint, suitable for a wide range of electronic applications.
