Introducing the PTN3360DBS,518 from NXP Semiconductors

The PTN3360DBS,518 is a highly versatile HDMI to VGA adapter IC that bridges the gap between legacy video infrastructure and modern digital interfaces. Manufactured by NXP Semiconductors, a leader in the electronics industry, this integrated circuit is designed to provide a seamless and high-quality conversion from HDMI signals to VGA outputs. It is an ideal solution for enabling devices with HDMI outputs to connect to displays that only support VGA inputs.

Key Features

• High-Quality Video Conversion: The PTN3360DBS,518 supports a wide range of video resolutions, ensuring that the highest quality video is maintained during the conversion process from digital to analog format.
• Plug and Play: This device requires no software or drivers, making it a true plug-and-play solution for quick and easy setup.
• EDID Support: The integrated Extended Display Identification Data (EDID) feature allows for automatic configuration of the connected display, ensuring optimal compatibility and performance.
• Low Power Consumption: Designed for efficiency, the PTN3360DBS,518 consumes minimal power, which is especially beneficial for battery-powered devices.
• Compact Design: The small form factor of the chip makes it an ideal choice for space-constrained applications.

Applications

The PTN3360DBS,518 is suited for a wide array of applications, including:

• Laptop and desktop computers that require a connection to VGA projectors or monitors
• Consumer electronics that need to interface with older display technologies
• Industrial and commercial systems that utilize VGA displays for monitoring and control interfaces

Technical Specifications

The PTN3360DBS,518 operates over a standard HDMI 1.4 interface and is capable of handling VGA output with a 165 MHz pixel clock rate, which is sufficient for resolutions up to 1080p or WUXGA (1920x1200). The device comes in a compact HVQFN32 package and is specified over a temperature range of -40°C to +85°C, making it robust for various environmental conditions.

With its ease of use, comprehensive feature set, and reliable performance, the PTN3360DBS,518 from NXP is the go-to solution for bridging modern digital devices with traditional VGA displays.
