Products specifications Report Issue?

Manufacturer NXP
Win Source Part Number 1238881-PMBFJ174
Manufacturer Homepage www.nxp.com
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian PMBFJ174 CAD Model

Description

The NXP PMBFJ174 is a high-performance, P-channel Junction Field Effect Transistor (JFET) designed for a wide range of applications. It is particularly suited for audio and analog signal switching and amplification due to its low noise and high input impedance characteristics.

Key Features:

  • High Input Impedance: The PMBFJ174 offers an exceptionally high input impedance, which makes it ideal for sensitive audio applications and impedance buffering.
  • Low Noise: With its low-noise performance, this JFET ensures a clean signal path, enhancing the quality of the final audio output.
  • Low On-Resistance: The low on-resistance of the PMBFJ174 allows for efficient signal conduction when the transistor is in the 'on' state, minimizing losses and improving performance.
  • Gate-Source Voltage: This JFET operates with a gate-source voltage (Vgs) that is suitable for a variety of analog applications, providing designers with flexibility in circuit design.
  • Through-Hole Package: The PMBFJ174 comes in a through-hole package, which is widely used and allows for easy mounting and soldering on printed circuit boards.

Applications:

The NXP PMBFJ174 is versatile and can be used in multiple applications, including but not limited to:

  • Audio Amplifiers
  • Switches
  • Buffer Stages
  • Analog Circuits
  • Signal Processing

Product Specifications:

Parameter Value Drain-Source Voltage (Vds) 30 V Gate-Source Voltage (Vgs) -30 V Drain Current (Id) 8 mA Power Dissipation (Pd) 300 mW

With its robust performance and reliable design, the NXP PMBFJ174 is a solid choice for professionals and hobbyists looking to enhance their electronic projects with a top-notch P-channel JFET.
