Overview of NXP PCF85063ATL/1,118

The NXP PCF85063ATL/1,118 is a highly integrated, low-power real-time clock/calendar (RTC) IC that provides an advanced timekeeping solution for a wide range of applications. This compact device is designed to maintain accurate timekeeping with minimal power consumption, making it ideal for battery-operated systems.

Key Features

• Timekeeping Accuracy: The device features a high-precision oscillator with a low-temperature coefficient, ensuring reliable timekeeping over a broad temperature range.
• Calendar Function: It includes a full calendar with day, month, and year information up to the year 2099, and also accounts for leap years automatically.
• Low Power Consumption: The PCF85063ATL/1,118 is optimized for low power consumption, making it suitable for battery-powered applications where energy efficiency is critical.
• Programmable Clock Output: A programmable clock output allows the device to be configured for various clock frequencies, providing flexibility for system design.
• I2C-Bus Interface: The device supports a fast I2C-bus interface for easy integration into a microcontroller-based system.
• Small Package: Housed in an ultra-small leadless package, the PCF85063ATL/1,118 saves valuable board space and is suitable for space-constrained applications.

Applications

The PCF85063ATL/1,118 is versatile and can be used in various applications such as:

• Portable electronics
• Wearable devices
• Smart meters
• Industrial and IoT devices
• Automotive electronics
• Data loggers

Technical Specifications

Below are some of the technical specifications for the NXP PCF85063ATL/1,118:

• Supply Voltage: 1.3 V to 5.5 V
• Frequency Range: 32.768 kHz
• Temperature Range: -40°C to +85°C
• Package: 8-pin HVSON

Overall, the NXP PCF85063ATL/1,118 RTC offers a compact, high-performance timekeeping solution that is easy to integrate into a variety of electronic systems, ensuring that they keep accurate time with minimal power consumption.
