Products specifications

Categories Integrated Circuits
Manufacturer NXP
Packaging Reel - TR
Status Active
Type Linear
Internal Switch(s) Yes
Number of Outputs 16
Operating Input Voltage(Min) 2.3V
Maximum Supply Voltage 5.5V
Output Voltage 5.5V
Channel Output Current 25mA
Dimming PWM
Applications Backlight
Temperature Range - Operating -40°C to 85°C (TA)
Mounting SMD (SMT)
Case / Package 28-HVQFN (6x6)
Win Source Part Number 137097-PCA9685BS,118
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian PCA9685BS,118 CAD Model

Description

Product Overview: PCA9685BS,118 - NXP Semiconductors

The PCA9685BS,118 is a sophisticated 16-channel, 12-bit PWM (Pulse Width Modulation) I²C-bus LED controller designed by NXP Semiconductors, renowned for their high-quality and innovative integrated circuits. This compact and efficient component is ideal for applications requiring multiple PWM outputs, such as LED color mixing, backlights, or general-purpose PWM outputs.

Key Features

  • High Flexibility: The PCA9685BS,118 offers 16 independently controlled PWM outputs, which can be used for dimming up to 16 separate LED channels. This makes it suitable for advanced lighting projects and RGB or RGBA LED drivers.
  • Adjustable Frequency: PWM output frequency is programmable and can be adjusted from a few hertz up to 1.6 kHz, providing versatility for various lighting effects and requirements.
  • 12-bit Resolution: With 12-bit resolution for each output, the device allows for fine-grained control of the PWM signal, enabling smooth transitions and precise control over the brightness levels.
  • I²C Interface: The PCA9685BS,118 utilizes an I²C-bus interface for communication, which supports up to 1008 different I²C-bus addresses through hardware address pins, making it easy to scale up systems with multiple devices without address conflicts.
  • External Clock Input: An external clock input is supported, allowing synchronization with other PWM devices or systems, which is essential for coordinated lighting or motor control applications.
  • Low Standby Current: It is designed with power efficiency in mind, featuring a low standby current which is crucial for battery-powered or energy-sensitive applications.

Applications

The PCA9685BS,118 is particularly well-suited for LED-related applications where multiple channels and fine control over brightness are required. Common use cases include:

  • RGB or RGBA LED drivers
  • Backlighting for LCD displays
  • LED status indication
  • Server and telecom infrastructure
  • Industrial control
  • Robotics

Its high resolution and flexibility in frequency adjustment also make it an excellent choice for advanced hobbyist projects in the fields of model making, DIY electronics, and custom lighting solutions.

With its robust feature set and the reliability of NXP Semiconductors, the PCA9685BS,118 is an indispensable component for designers and engineers looking to create sophisticated and power-efficient PWM control systems.
