The MCF52258CAG66R is a high-performance microcontroller unit (MCU) designed and manufactured by NXP Semiconductors. This MCU is part of the MCF5225x family that features the V2 ColdFire core with enhanced capabilities, making it suitable for a wide range of industrial and consumer applications.

Key Features

• Core: The device is built around a 32-bit V2 ColdFire core that provides a perfect balance between processing power and low power consumption, operating at a maximum frequency of 66 MHz.
• Memory: It comes with 512 KB of flash memory and 64 KB of SRAM, offering ample space for complex applications and data storage.
• Connectivity: The MCU provides a variety of communication interfaces, including Ethernet, USB OTG, CAN, UART, I2C, SPI, and more, enabling easy integration into different systems and networks.
• Timers and Counters: Equipped with multiple timers, including a real-time timer, and PWM controllers, the MCF52258CAG66R is adept at handling timing-sensitive tasks.
• Analog Features: It features an onboard 12-bit analog-to-digital converter (ADC) with up to 16 channels, allowing for precise measurement of analog signals.
• Package: The MCU is available in a 144-pin MAPBGA package, which is ideal for space-constrained applications.
• Operating Temperature: The device is designed to operate within the industrial temperature range, ensuring reliable performance under varying environmental conditions.

Applications

The MCF52258CAG66R MCU is versatile and can be used in a variety of applications, such as:

• Industrial control systems
• Home automation
• Medical devices
• Networking equipment
• Automotive control units

Design Support

NXP offers comprehensive design support for the MCF52258CAG66R, including technical documentation, development tools, and software libraries. This support helps to accelerate the development process and reduce time-to-market for products utilizing this advanced MCU.
