The NXP MC9S08DZ60ACLH is a highly integrated microcontroller designed for embedded systems requiring a high-performance, low-power solution. This microcontroller is part of NXP's S08D family and is built on the HCS08 core, which is well-known for its robustness and efficiency. The device features a 60KB flash memory, making it suitable for applications with complex software requirements or those that need to store significant amounts of data.

Key Features

• CPU: 8-bit HCS08 Central Processing Unit (CPU) with a maximum bus frequency of 40 MHz, providing a solid balance between processing power and power consumption.
• Memory: Comes with 60KB of on-chip in-circuit programmable flash memory and 4KB of RAM, offering ample space for application code and data storage.
• Timers: Includes an array of timers such as two 8-channel, 16-bit timer/pulse-width modulators (TPM) for precise event timing and waveform generation.
• Analog-to-Digital Converter (ADC): Features a 12-channel, 12-bit ADC with automatic compare function and temperature sensor, enabling the microcontroller to interface with analog sensors and transducers.
• Communication Interfaces: Equipped with multiple communication interfaces including one SCI (Serial Communication Interface) and one SPI (Serial Peripheral Interface), facilitating easy data exchange with peripherals.
• Input/Output: Offers up to 51 general-purpose input/output (GPIO) pins for versatile connectivity with external devices.
• Operating Voltage: Operates at a voltage range from 2.7V to 5.5V, suitable for battery-operated and power-sensitive applications.

Applications

The MC9S08DZ60ACLH is ideal for a diverse range of applications, including but not limited to industrial control systems, automotive electronics, home automation, and consumer electronics. Its rich set of features and low-power operation make it a preferred choice for designers looking to optimize their systems for performance and power efficiency.

Package and Quality

The microcontroller is available in a 64-LQFP (Low Profile Quad Flat Package), which is compact and suitable for space-constrained applications. NXP's commitment to quality ensures that the MC9S08DZ60ACLH meets stringent standards, providing reliable performance in demanding environments.
