Products specifications

Category Integrated Circuits (ICs)>PMIC - Motor Drivers, Controllers
Mfr NXP USA Inc.
Package Tape & Reel (TR)
Function Controller - Commutation, Direction Management
Output Configuration Half Bridge (3)
Interface SPI
Technology Power MOSFET
Applications Automotive
Voltage - Supply 6V ~ 58V
Voltage - Load 6V ~ 58V
Temperature Range - Operating -40°C ~ 125°C (TA)
Mounting SMD (SMT)
Package / Case 56-VFQFN Exposed Pad
Supplier Device Package 56-QFN (8x8)
Base Product Number MC33GD3000
MSL Level 3 (168 Hours)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8542.39.0001
Other Names 935316315528
Standard Package 2,000
Win Source Part Number 1077264-MC33GD3000EPR2
Ultra Librarian 3D Model Ultra Librarian MC33GD3000EPR2 CAD Model

Description

Introducing the MC33GD3000EPR2 Pre-Driver from NXP Semiconductors

The MC33GD3000EPR2 is a cutting-edge gate driver integrated circuit (IC) designed by NXP Semiconductors, a leader in automotive and industrial technology solutions. This advanced pre-driver IC is specifically engineered to meet the demanding requirements of automotive and industrial motor control applications. It is well-suited for driving high-power, high-speed IGBTs and power MOSFETs.

Key Features

  • High Voltage Capability: The MC33GD3000EPR2 can handle up to 36V of operating voltage, making it suitable for a wide range of power applications.
  • Advanced Protection: It includes features such as under-voltage lockout, over-current protection, and thermal shutdown to ensure the safety and reliability of your system.
  • Dual-Channel Operation: With dual-channel output, it can control two independent gates, which is ideal for half-bridge configurations commonly found in motor control circuits.
  • High Current Drive: The device can provide high peak current drive capability, ensuring rapid charging and discharging of the gate capacitance for fast switching of power devices.
  • Flexible Input Interface: It is compatible with both CMOS and LSTTL logic level inputs, providing versatility in interfacing with different control units.

Applications

The MC33GD3000EPR2 is primarily used in automotive applications, such as electric power steering, engine cooling fans, and electric pumps. Additionally, it finds its use in industrial applications where precise and efficient motor control is critical, such as in robotics, conveyors, and compressors.

Quality and Reliability

NXP Semiconductors is committed to delivering high-quality products. The MC33GD3000EPR2 is designed with automotive-grade robustness, ensuring it meets the stringent standards for performance and reliability required in the automotive industry. This pre-driver is also suitable for harsh industrial environments where reliability is paramount.

Design Support

NXP provides comprehensive design support for the MC33GD3000EPR2, including detailed datasheets, application notes, and reference designs. This enables engineers to accelerate the development process and reduce time-to-market for their products.

With its robust design, advanced protection features, and flexible operation, the MC33GD3000EPR2 from NXP Semiconductors is an excellent choice for your next high-performance motor control application.
