The NXP JN5168-001-M03Z is a versatile microcontroller module designed for the implementation of robust and efficient wireless networks. Built around the JN5168 microcontroller, this compact module is perfect for applications in the Internet of Things (IoT), home and building automation, and other smart network systems.

Key Features

• High Performance: The JN5168-001-M03Z is equipped with a 32-bit RISC processor that provides high computational power, enabling complex applications to run smoothly and efficiently.
• Integrated Memory: With 256 KB of embedded Flash, 32 KB of RAM, and 4 KB of EEPROM, this module offers ample memory resources for both program storage and dynamic data management.
• Wireless Connectivity: Featuring a built-in 2.4 GHz IEEE 802.15.4 compliant transceiver, the module supports Zigbee, JenNet-IP, and other IEEE 802.15.4-based network protocols, ensuring flexible and reliable wireless communication.
• Low Power Consumption: Designed for energy efficiency, the module includes a power-saving mode that significantly extends battery life, making it ideal for battery-powered devices.
• Compact Design: The small footprint of the module (23 x 27 x 3 mm) allows for easy integration into space-constrained applications.
• Easy Integration: The JN5168-001-M03Z comes with 21 general-purpose I/O pins, enabling seamless connection with sensors, actuators, and other peripherals.

Applications

This module is well-suited for a variety of applications, including:

• Smart Lighting Systems
• Home Automation Controls
• Security and Surveillance Systems
• Industrial Monitoring and Control
• Wireless Sensor Networks

Development Support

NXP also provides comprehensive development support for the JN5168-001-M03Z module, including software development kits (SDKs), reference designs, and technical documentation to facilitate rapid product development and time-to-market.
