Products specifications Report Issue?

Reference Date Code 17+
Manufacturer NXP
Manufacturer Homepage www.nxp.com
Win Source Part Number 709800-BUK9Y41-80E
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Family Name BUK9Y41-80E
Introduction Date February 20, 2013
ECCN EAR99
Country of Origin Philippines
Halogen Free Compliant
Estimated EOL Date 2029
Ultra Librarian 3D Model Ultra Librarian BUK9Y41-80E CAD Model

Description

Product Overview: BUK9Y41-80E

The BUK9Y41-80E is a cutting-edge, high-efficiency Power MOSFET from NXP Semiconductors, designed to meet the demands of modern electronic applications. This device is part of NXP's portfolio of TrenchMOS™ technology, which is renowned for its low on-state resistance, high switching speed, and superior thermal performance.

Key Features

  • Low On-State Resistance (R<sub>DS(on)): The BUK9Y41-80E boasts an extremely low on-state resistance, which minimizes conduction losses and improves overall efficiency, making it ideal for high current applications.
  • High-Speed Switching: With its fast switching capabilities, this MOSFET is well-suited for high-frequency operations, reducing switching losses and enhancing performance in power conversion applications.
  • Enhanced Thermal Performance: The device is encapsulated in a robust package that enhances heat dissipation, ensuring reliable operation even under high temperature conditions.
  • Voltage Rating: It is designed to handle voltages up to 80V, making it suitable for a wide range of applications in automotive, industrial, and consumer electronics.
  • Energy Efficiency: The TrenchMOS™ technology used in the BUK9Y41-80E allows for lower gate charge and reduced capacitance, leading to lower power consumption and improved energy efficiency.

Applications

The versatility of the BUK9Y41-80E allows it to be used in a variety of applications, including:

  • DC/DC converters
  • Motor control circuits
  • Power management systems
  • Automotive applications such as electric power steering, DC motor drives, and LED lighting
  • Switch Mode Power Supplies (SMPS)
  • Load switches

Quality and Reliability

NXP Semiconductors is committed to delivering high-quality and reliable components. The BUK9Y41-80E is no exception, undergoing rigorous testing and quality control measures to ensure it meets the industry standards for performance and durability. It is designed to provide a long operational lifespan even in the most demanding environments.

Whether you are designing power systems for automotive technology, industrial automation, or energy-efficient consumer electronics, the BUK9Y41-80E from NXP offers the performance, efficiency, and reliability needed to drive your innovations forward.
