Products specifications

Category Discrete Semiconductor Products - Transistors - FETs, MOSFETs - FET, MOSFET Arrays
Mfr NXP USA Inc.
Package Bulk
Technology MOSFET (Metal Oxide)
Configuration 2 N-Channel (Dual)
Drain to Source Voltage (Vdss) 100V
Current - Continuous Drain (Id) @ 25°C 29A
Rds On (Max) @ Id, Vgs 27.5mOhm @ 5A, 10V
Vgs(th) (Max) @ Id 4V @ 1mA
Gate Charge (Qg) (Max) @ Vgs 34nC @ 10V
Input Capacitance (Ciss) (Max) @ Vds 2137pF @ 25V
Power - Max 64W
Temperature Range - Operating -55°C ~ 175°C (TJ)
Mounting Type Surface Mount
Package / Case SOT-1205, 8-LFPAK56
Supplier Device Package LFPAK56D
Base Product Number BUK7K32
Standard Package 1
ECCN EAR99
HTSUS 8541.29.0095
Win Source Part Number 1342678-BUK7K32-100EX
Ultra Librarian 3D Model Ultra Librarian BUK7K32-100EX CAD Model

Description

The BUK7K32-100EX is a high-performance, N-channel TrenchMOS™ standard level FET manufactured by NXP Semiconductors. Renowned for its efficiency and reliability, this power MOSFET is designed to deliver optimal performance in a wide array of applications, ranging from automotive to industrial systems.

Key Features

  • Low On-state Resistance: The BUK7K32-100EX boasts an extremely low on-state resistance (R<sub>DS(on)), which significantly reduces conduction losses and improves overall system efficiency.
  • High-Speed Switching: With its fast switching capabilities, this MOSFET enables high-frequency operation, making it suitable for modern, high-efficiency power supplies and converters.
  • Robust Thermal Performance: The device's excellent thermal characteristics ensure reliable operation even under high current and temperature conditions.
  • Standard Level Gate Drive: Its standard level gate drive allows for ease of control and is compatible with a wide range of drive circuits.

Applications

The BUK7K32-100EX is versatile and can be used in various applications, including but not limited to:

  • DC/DC converters
  • Motor drives
  • Automotive applications such as engine management and powertrain systems
  • Power management systems
  • Switched mode power supplies (SMPS)

Product Specifications

Parameter Value Drain-source voltage (V<sub>DS) 100V Continuous drain current (I<sub>D) 100A Power dissipation (P<sub>tot) 348W Operating temperature range -55°C to +175°C

The BUK7K32-100EX is a testament to NXP's commitment to providing cutting-edge technology that meets the stringent requirements of modern electronic systems. With its robust design and superior electrical characteristics, this MOSFET is an excellent choice for engineers looking to enhance system performance and reliability.
