Products specifications

Category RF/IF and RFID>RF Amplifiers
Mfr NXP USA Inc.
Package Tape & Reel
Frequency 40MHz ~ 4GHz
P1dB 9.5dBm
Gain 19dB
Noise Figure 2.3dB
RF Type General Purpose
Voltage - Supply 1.5V ~ 5V
Current - Supply 20mA
Test Frequency 3.5GHz
Mounting SMD (SMT)
Package / Case 6-XFDFN Exposed Pad
Supplier Device Package 6-HXSON (1.3x2)
Base Product Number BGU6102
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8542.33.0001
Other Names BGU6102147,NXPNXPBGU6102,147,568-10150-1,568-10150-2,2156-BGU6102,147,568-10150-6,BGU6102,147-ND,934065666147
Standard Package 5,000
Win Source Part Number 991105-BGU6102,147
Ultra Librarian 3D Model Ultra Librarian BGU6102,147 CAD Model

Description

The BGU6102,147 is a high-performance, low-noise amplifier (LNA) designed and manufactured by NXP Semiconductors. This advanced LNA is specifically engineered for a wide range of applications, including but not limited to satellite TV receivers, GPS, ISM, and various other RF applications. The BGU6102,147 is recognized for its exceptional noise figure, high gain, and robust linearity which make it an ideal choice for systems where superior signal amplification is required.

Key Features

  • High Gain: The BGU6102,147 offers a high gain level, which is essential for weak signal amplification in RF circuits, ensuring clear and strong output signals.
  • Low Noise Figure: With its low noise figure, this LNA minimizes additional noise in the signal path, thereby improving the signal-to-noise ratio (SNR) and overall system sensitivity.
  • Wide Frequency Range: The device operates over a broad frequency range, making it versatile for various communication bands and applications.
  • Power Efficiency: The BGU6102,147 is designed for power-efficient operation, which is critical for battery-powered devices and systems that require long-term, continuous operation.
  • Robust Linearity: High linearity ensures that the amplifier can handle a wide range of input signal levels without distorting the output signal, which is crucial for maintaining signal fidelity.

Applications

The BGU6102,147 from NXP is suitable for a variety of applications, including:

  • Satellite TV receivers, where high-quality signal amplification is necessary for clear audio and video reception.
  • Global Positioning System (GPS) receivers, which rely on amplifying weak satellite signals for accurate positioning and navigation.
  • Industrial, Scientific, and Medical (ISM) band applications, where reliable signal transmission and reception are required.
  • General RF applications that benefit from low noise amplification to enhance system performance.

Technical Specifications

Parameter Value Manufacturer NXP Semiconductors Product Category RF Amplifiers RoHS Yes Gain Details available in datasheet Noise Figure Details available in datasheet Operating Frequency Details available in datasheet

For more detailed specifications and application notes, customers are advised to consult the official NXP datasheets and product guides.
