Manufacturer NXP
Win Source Part Number 1132568-74LV165PW
Manufacturer Homepage www.nxp.com
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian 74LV165PW CAD Model

Description

Product Overview: 74LV165PW from NXP

The 74LV165PW is a high-performance, low-voltage 8-bit parallel-load shift register produced by NXP Semiconductors. This integrated circuit (IC) is designed for use in systems that require the capture and serial transfer of parallel data. The 74LV165PW is part of the 74LV family, which operates on a low-voltage power supply, ranging from 2.0V to 5.5V, making it suitable for battery-operated devices and low-power applications.

Key Features

  • Parallel-to-Serial Data Conversion: The device converts 8-bit parallel input data into serial output data, which can be read by a microcontroller or another digital system.
  • Low Power Consumption: With its LV (low-voltage) technology, the 74LV165PW is optimized for minimal power consumption while maintaining high-speed operation.
  • Wide Operating Voltage: The IC operates across a wide voltage range, accommodating various logic level requirements.
  • Shift Register Mode: The shift register has a direct overriding clear (SRCLR) input, clock (CP) input, and clock enable (CE) input to ensure flexible control of the data shifting process.

Applications

The 74LV165PW is versatile and can be used in a variety of applications, including:

  • Remote data acquisition systems
  • Serial-to-parallel data conversion
  • Data logging devices
  • Interface circuitry for microprocessors
  • Instrumentation and control systems

Package and Quality

The 74LV165PW comes in a TSSOP16 (Thin Shrink Small Outline Package) which is suitable for surface-mount technology (SMT). The compact package size allows for efficient use of board space in dense electronic designs. NXP's commitment to quality ensures that this device meets stringent industry standards for performance and reliability.

Conclusion

The NXP 74LV165PW is an ideal choice for designers looking for a reliable and power-efficient solution to interface parallel and serial data in their digital systems. With its broad operating voltage range, low power consumption, and compact packaging, this shift register provides a flexible and efficient solution for a wide range of applications.
