nRF51822-CEAA-R Nordic Semiconductors
Same model may have multiple batches, images only for reference.

nRF51822-CEAA-R

Part No nRF51822-CEAA-R
Manufacturer Nordic Semiconductors
Catalog RF Transceiver ICs
Description IC RF TXRX+MCU BLUETOOTH 62UFBGA
Datasheet
nRF51822-CEAA-R Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category RF and Wireless - RF Transceiver ICs
Mfr Nordic Semiconductors
Package Tape & Reel
Product Status Not For New Designs
Programmable Not Verified
Type TxRx + MCU
RF Family/Standard Bluetooth, General ISM > 1GHz
Protocol Bluetooth v4.0
Modulation GFSK
Frequency 2.4GHz
Data Rate (Max) 2Mbps
Power - Output 4dBm
Sensitivity -96dBm
Memory Size 256kB Flash, 16kB RAM
Serial Interfaces I2C, SPI, UART
GPIO 32
Voltage - Supply 1.8V ~ 3.6V
Current - Receiving 9.7mA ~ 13.4mA
Current - Transmitting 4.7mA ~ 16mA
Temperature Range - Operating -25°C ~ 75°C
Mounting Type Surface Mount
Package / Case 62-UFBGA, WLCSP
Supplier Device Package 62-WLCSP (3.5x3.83)
Base Product Number NRF51822
Standard Package 3,000 pcs
MSL Level 2 (1 Year)
REACH Status REACH Unaffected
ECCN 5A992C
HTSUS 8542.31.0001
Win Source Part Number 843519-nRF51822-CEAA-R
Ultra Librarian 3D Model Ultra Librarian nRF51822-CEAA-R CAD Model

Description

The nRF51822-CEAA-R is a high-performance RF transceiver IC with an integrated MCU, manufactured by Nordic Semiconductors.

  • Frequency: 2.4GHz
  • Protocol: Bluetooth v4.0
  • Memory Size: 256kB flash and 16kB RAM
  • Power Output: 4dBm
  • Sensitivity: -96dBm
  • Serial Interfaces: I2C, SPI, and UART
  • Voltage Supply Range: 1.8V to 3.6V
  • Operating Temperature: -25°C to 75°C
  • Mounting Type: Surface Mountable
  • Package: 62-UFBGA
