NJM2904CG-TE2

Name: NJM2904CG-TE2
Brand: Nisshinbo Micro Devices Inc.
SKU: 255283
Availability: InStock
Rating: 4.85 (5 reviews)

Get a Quote

Part No	NJM2904CG-TE2
Manufacturer	Nisshinbo Micro Devices Inc.
Catalog	Linear - Amplifiers - Instrumentation, OP Amps, Buffer Amps
Description	IC OPAMP GP 2 CIRCUIT 8SOP
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Category	Integrated Circuits (ICs) - Linear - Amplifiers - Instrumentation, OP Amps, Buffer Amps
Mfr	Nisshinbo Micro Devices Inc.
Package	Tape & Reel
Product Status	Active
Amplifier Type	General Purpose
Number of Circuits	2
Slew Rate	0.6V/µs
Current - Input Bias	20 nA
Voltage - Input Offset	500 µV
Current - Output / Channel	40 mA
Voltage - Supply Span (Min)	3 V
Voltage - Supply Span (Max)	32 V
Temperature Range - Operating	-40°C ~ 125°C
Mounting Type	Surface Mount
Package / Case	8-SOIC (0.154", 3.90mm Width)
Supplier Device Package	8-SOP
Base Product Number	NJM2904
Standard Package	2,500 pcs
Moisture Sensitivity Level (MSL)	1 (Unlimited)
ECCN	EAR99
HTSUS	8542.33.0001
Win Source Part Number	255283-NJM2904CG-TE2
Ultra Librarian 3D Model	Ultra Librarian NJM2904CG-TE2 CAD Model

Alternative Products

Description

The NJM2904CG-TE2 is a dual general-purpose operational amplifier with a slew rate of 0.6V/μs.

Applications: wide range of applications in the field of linear amplifiers and instrumentation
Current Input Bias: 20nA
Voltage Input Offset: 500μV
Current Output: 40mA per channel
Package: 8-SOIC package
Mounting: surface mountable
Operating Temperature Range: -40°C to 125°C
Features: high-quality design and excellent performance characteristics
