NJM2670E3-TE2 NJR Corporation/NJRC
Same model may have multiple batches, images only for reference.

NJM2670E3-TE2

Part No NJM2670E3-TE2
Manufacturer Nisshinbo Micro Devices Inc.
Catalog PMIC - Motor Drivers, Controllers
Description IC H-BRIDGE DRIVER DUAL 24-EMP
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Integrated Circuits (ICs) - Power Management (PMIC) - Motor Drivers, Controllers
Mfr Nisshinbo Micro Devices Inc.
Package Tape & Reel
Product Status Obsolete
Motor Type - Stepper Bipolar
Motor Type - AC, DC Brushed DC
Function Driver - Fully Integrated, Control and Power Stage
Output Configuration Half Bridge (4)
Interface Parallel
Technology Bipolar
Applications General Purpose
Current - Output 1.3A
Voltage - Supply 4.75V ~ 5.25V
Voltage - Load 4V ~ 55V
Temperature Range - Operating -40°C ~ 85°C
Mounting Type Surface Mount
Package / Case 24-SOIC (0.295", 7.50mm Width)
Supplier Device Package 24-SOP
Base Product Number NJM2670
Standard Package 1,500 pcs
ECCN OBSOLETE
Win Source Part Number 254634-NJM2670E3-TE2
Ultra Librarian 3D Model Ultra Librarian NJM2670E3-TE2 CAD Model

Description

The NJM2670E3-TE2 is an integrated circuit motor driver and controller.

  • Application: It is designed for general purpose applications.
  • Output Current: The output current is 1.3A
  • Voltage Load: and the voltage load range is 4V to 55V.
  • Mounting Style: This device is surface mountable
  • Package: and comes in a 24-SOIC package.
  • Operating Temperature: The operating temperature range is -40°C to 85°C.
  • Manufacturer: It is manufactured by Nisshinbo Micro Devices Inc.
