TB6568KQ,8 Toshiba Semiconductor and Storage
Same model may have multiple batches, images only for reference.

TB6568KQ,8

Part No TB6568KQ,8
Manufacturer Toshiba Semiconductor and Storage
Catalog PMIC - Motor Drivers, Controllers
Datasheet
TB6568KQ,8 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Integrated Circuits (ICs)>PMIC - Motor Drivers, Controllers
Mfr Toshiba Semiconductor and Storage
Package Tray
Motor Type - AC, DC Brushed DC
Function Driver - Fully Integrated, Control and Power Stage
Output Configuration Half Bridge (2)
Interface Parallel
Technology Bi-CMOS
Applications General Purpose
Current - Output 1.5A
Voltage - Supply 10V ~ 45V
Voltage - Load 10V ~ 45V
Temperature Range - Operating -40°C ~ 85°C (TA)
Mounting Type Through Hole
Package / Case 7-SIP Exposed Tab
Supplier Device Package 7-HSIP
Base Product Number TB6568
MSL Level 1 (Unlimited)
ECCN EAR99
HTSUS 8542.39.0001
Win Source Part Number 1315951-TB6568KQ,8
Ultra Librarian 3D Model Ultra Librarian TB6568KQ,8 CAD Model

Description

The TB6568KQ is a bi-CMOS integrated circuit designed for driving a brushed DC motor.

  • Product Name: TB6568KQ
  • Description: Bi-CMOS integrated circuit for driving a brushed DC motor
  • Features: Fully integrated driver with control and power stages
  • Interface: Parallel
  • Output Current: Up to 1.5A
  • Output Configuration: Half bridge with two outputs
  • Voltage Load Range: 10V to 45V
  • Mounting: Through hole
  • Package: 7-SIP exposed tab
  • Operating Temperature Range: -40°C to 85°C
  • Application: General-purpose motor driver
