CS-32-12ZETA Nidec Copal Electronics
Same model may have multiple batches, images only for reference.

CS-32-12ZETA

Part No CS-32-12ZETA
Manufacturer Nidec Copal Electronics
Catalog DIP Switches
Description SWITCH ROTARY DIP SPDT 100MA 16V
Datasheet
CS-32-12ZETA Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Switches - DIP Switches
Mfr Nidec Components Corporation
Series CS-32
Package Tape & Reel
Product Status Active
Circuit SPDT
Number of Positions 2
Current Rating (Amps) 100mA
Voltage Rating 16VDC
Actuator Type Rotary for Tool
Actuator Level Flush, Recessed
Contact Material -
Contact Finish -
Height Above Board 0.079" (2.00mm)
Mounting Type Surface Mount
Termination Style J Lead
Pitch -
Washable Yes
Features -
Temperature Range - Operating -40°C ~ 85°C
Body Material Epoxy
Length 0.134" (3.40mm)
Mechanical Life -
Electrical Life 50 Cycles
Base Product Number CS-32-12
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8536.50.9065
Win Source Part Number 1376111-CS-32-12ZETA
Ultra Librarian 3D Model Ultra Librarian CS-32-12ZETA CAD Model

Description

The Nidec Components Corporation CS-32-12ZETA is a surface mount DIP switch with 2 positions.

  • Temperature Range: -40°C to 85°C
  • Current Rating: 100mA
  • Voltage Rating: 16VDC
  • Circuit Configuration: SPDT
  • Actuator Type: Rotary
  • Termination Style: J Lead
  • Mechanical Life: 50 cycles
  • Washable: Yes
  • Height Above Board: 0.079" (2.00mm)
  • Body Material: Epoxy
  • Product Status: Active
  • Series: CS-32
