PHN203,518 Nexperia USA Inc. – Price, Stock & Datasheet
Same model may have multiple batches, images only for reference.

PHN203,518

Part No PHN203,518
Manufacturer Nexperia USA Inc.
Catalog Transistors - FETs, MOSFETs Arrays
Description MOSFET 2N-CH 30V 6.3A 8SO
Sample
Rohs State Need to verify
ECAD Module
Need Help

Products specifications Report Issue?

Technology MOSFET (Metal Oxide)
Configuration 2 N-Channel (Dual)
FET Feature Logic Level Gate
Drain to Source Voltage (Vdss) 30V
Current - Continuous Drain (Id) @ 25°C 6.3A (Ta)
Rds On (Max) @ Id, Vgs 30mOhm @ 7A, 10V
Vgs(th) (Max) @ Id 2V @ 1mA
Gate Charge (Qg) (Max) @ Vgs 14.6nC @ 10V
Input Capacitance (Ciss) (Max) @ Vds 560pF @ 20V
Power - Max 2W (Ta)
Temperature Range - Operating -55°C ~ 150°C (TJ)
Mounting Type Surface Mount
Case / Package 8-SOIC (0.154", 3.90mm Width)
Supplier Device Package 8-SO
Package Bulk
Supply and Demand Status Shortage
Win Source Part Number 1495238-PHN203,518
Ultra Librarian 3D Model Ultra Librarian PHN203,518 CAD Model
