HEF4053BT,653

Part No HEF4053BT,653
Manufacturer Nexperia USA Inc.
Catalog Interface - Analog Switches, Multiplexers, Demultiplexers
Description IC MUX/DEMUX TRIPLE 2X1 16SOIC
Datasheet
HEF4053BT,653 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Nexperia USA Inc.
Packaging Reel - TR
Status Active
Switch Circuit SPDT
Number of Circuits 3
Max On Resistance 155 Ohm
Channel-to-Channel Matching (ΔRon) 5 Ohm
Single Supply Voltage (V+) 3 V to 15 V
-3db Bandwidth 70MHz
Channel Capacitance(CS off, CD off) 7.5pF
Max Leakage Current (IS off) 200nA
Crosstalk -50dB @ 1MHz
Temperature Range - Operating -40°C to 125°C (TA)
Case / Package 16-SO
Win Source Part Number 1043119-HEF4053BT,653
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian HEF4053BT,653 CAD Model

Description

The Nexperia HEF4053BT,653 is a 3-channel SPDT switch circuit integrated circuit.

  • -3db Bandwidth: 70MHz
  • Channel-to-Channel Matching (ΔRon): 5 Ohm
  • Max On Resistance: 155 Ohm
  • Channel Capacitance (CS off, CD off): 7.5pF
  • Package: 16-SO
  • Single Supply Voltage Range: 3 V to 15 V
  • Applications: Variety of Applications
